| Quantity: | |
|---|---|
Model | Unit | ELB-01 | ELB-02 | ELB-04 | ELB-06 | ELB-08 | ELB-08S | ELB-10 |
Open width | mm | - | 1032 | 1344 | 1723 | 2100 | 2100 | 2500 |
Hight | mm | - | 420 | 600 | 750 | 850 | 900 | 1020 |
W idth | mm | - | 75 | 95 | 112 | 180 | 180 | 360 |
Crushing force D | KN | - | 260 | 510 | 650 | 1170 | 1170 | 1500 |
Crushing force E | KN | - | 170 | 260 | 470 | 994 | 994 | 1350 |
Working pressure | Mpa | - | 24 | 24 | 31 | 32 | 32 | 32 |
Hydraulic Flow | Lpm | - | 80-120 | 100-140 | 120-180 | 180-250 | 180-250 | 200-300 |
Excavator weight | ton | - | 3-5T | 6-9T | 10-15T | 15-25T | 20-30T | 30-36T |
Weight | kg | - | 270 | 480 | 880 | 1600 | 1980 | 2500 |
