| Quantity: | |
|---|---|
Model | Unit | ELB-00 | ELB-01 | ELB-02 | ELB-04 | ELB-06 | ELB-08 | ELB-10 |
Length | mm | - | 800 | 900 | 900 | 1160 | 1300 | 1500 |
Height | mm | - | 435 | 530 | 530 | 650 | 720 | 730 |
Width | mm | - | 442 | 550 | 550 | 700 | 900 | 900 |
Impulse force | ton | - | 3 | 4 | 4 | 6.5 | 11 | 15 |
Vibration frequency | rpm/min | - | 2000 | 2000 | 2000 | 2000 | 2200 | 2200 |
Oil flow | l/min | - | 30-60 | 45-85 | 45-85 | 85-105 | 120-170 | 120-170 |
Operating pressure | kg/cm² | - | 100-130 | 100-130 | 100-130 | 100-150 | 150-200 | 150-200 |
Bottom measurement | mm | - | 800*442 | 900*550 | 900*550 | 1160*700 | 1300*900 | 1500*1000 |
Excavator weight | ton | - | 2-4 | 4-6 | 6-10 | 12-16 | 18-24 | 30-40 |
Weight | kg | - | 200 | 350-500 | 350-500 | 650-800 | 900-1000 | 1100-1300 |
